HDM-ENW
- HDTV resolution up to 1080p@60.
- HDMI signal up to 100 meter on HDTV.
- Use CAT.5/5E/6 cable to install easily.
- Support RS-232.
- HDMI Compliant.
- HDCP Compliant.
- RS-232 Extender.
- Supports Web server system setup.
- Supports《IPTV_Control_Center》control.
-
Function HDMI-LNW HDMI-RNW HDMI In Connector 1 (HDMI A-Type Female) None HDMI Out Connector 1 (HDMI A-Type Female) LED indicators POWER LINK RJ-45 Connector x 1 IR2 IN None 3.5φ Stereo Jack x 1 IR OUT 3.5φ Stereo Jack x 1 None IR Carrier Frequency 20KHz ~ 60KHz BAUD RATE SETTING 3 PIN DIP SWITCH DIP SW 8 PIN DIP SWITCH Power Adapter (Min.) DC 12V with lock HDMI Output Max. Resolution 1080p@60 (8Bits) 1080p@60 (8Bits) HDMI Output (Color Space) YCbCr 4:4:4 RGB Cat.5e Cable Distance 100 meters (Max.) RS-232 Connector DB9 Female x 1 Baud Rate 2400 up to 115200 bps; 8 data bits, 1 stop bit, no parity Housing Metal Weight 338g 330g Dimensions (LxWxH) 150x80x35mm -
1x HDM-LNW and HDM-RNW Unit
1 user manual
1x Power adapter DC 12V with lock
2x screws
4x foot pads
1x IR receiver cable
1x IR blaster cable (Peak Wavelength 940nm)
